Heretic Studio

40" Amber Curved LED Light Bar

Sale price$974.99 USD
Beam Pattern:

Beam Pattern

Quantity:

40” Performance and aesthetics:

Overview

The Heretic 40" Amber Curved LED light bar is a beast of a light when it comes to LED light bars. They are Designed, Assembled, Supported, and Shipped in Centerville, Utah. It truly turns darkness into light. This high performance 6-series curved amber LED light bar is housed in CNC machined aircraft-grade aluminum, and outfitted with best-in-class circuit boards that allow temperature control and long-lasting light. The 40” Amber Curved LED light bar is recommended for forward-facing applications in aftermarket roof racks like PRINSU and UTV roll cages. This light bar is best optimized for foggy and dusty conditions. Customize your light by choosing the beam pattern, Flood, Spot, Or Combo. With bracket included this becomes a 42" Amber Curved LED Light Bar.

Features

  • USA Patented 6061 CNC Aluminum Grade Billet Housing
  • (40) 6-watt CREE LED
  • IP68 rated Stainless Steel Mounts

Vehicle Application

Typically forward-facing placement for UTV roll cages that have a curved design. Requires aftermarket mount.

Parts Sold Separately

  • Wiring Harness
  • Aftermarket Mount for Roof Rack Attachment


Details/Specs

Shipping Weight: 8lbs
Type: 40” LED Light Bar
Housing: CNC Aircraft-Grade Aluminum
Location: Roof, Bumper, Grille, Rack
Light Color: White
Lens Color: Clear
Wattage: 240W
Amp Draw at 13.8V: 25.4A
Voltage: 9V-36V
IP Rating: IP68
DIM (Light Only): L 41” x D 1.5” x H 2”
DIM (Light W/ Bracket): L 42” x D 1.5” x H “2.4
Lumens: 30,000 lm
Lux At 10m:
  • Spot: 8250 lx
  • Flood: 1755 lx
  • Combo: 5652 lx
Candela:
  • Spot: 825000 cd
  • Flood: 1175500 cd
  • Combo: 565200 cd
Beam Distance:
  • Spot: 1817 m
  • Flood: 838 m
  • Combo: 1504 m
DOT Compliant: No
Prop 65: No
SAE/ECE: No
